TOUGHFAN 14 High Static Pressure Radiator Fan (Single Fan Pack) Black

Thermaltake TOUGHFAN PWM-controlled high static pressure fan features an optimized structure to maximize high-end cooling needs.

Unparalleled Cooling Performance

The TOUGHFAN is a PWM controlled fan which is designed to perform at a maximum operating speed of up to 2000 RPM allowing unparalleled cooling performance.

Exceptional Blade Design

Featuring high tensile strength and low thermal expansion coefficient materials, the fan blade is built with special liquid crystal polymer (LCP), a compound which minimizes vibration when the fan is operating at full speed.

Metal-Reinforced Motor Hub

The TOUGHFAN’s center is constructed with a full steel motor hub providing enhanced stability and durability.

Specifications

Fan Dimensions

140 x 140 x 25 mm
FAN STARTED VOLTAGE

9.0 V
FAN RATED VOLTAGE

12 V
Fan Rated Current

0.34 A (Fan x1)
POWER INPUT

4.08 W (Fan x1)
Fan Speed

PWM 500~2000 R.P.M
With L.N.C PWM 500~1300 R.P.M
MAX. AIR PRESSURE

3.54 mm-H2O
MAX AIR FLOW

119.1 CFM
NOISE LEVEL

33.2 dB-A
With L.N.C 25.2 dB-A
BEARING TYPE

Hydraulic Bearing Gen.2
LIFE EXPECTATION

40,000 hrs,25℃
CONNECTOR

4 PIN PWM
Weight

240.7 g
